Zuken CR-8000 connector

Integration of pure::variants with an ECAD tool. Control variation points in your board design via feature modeling.

Our Connector for Zuken CR-8000 enables users to formally manage the variability within Zuken CR-8000 Design Gateway projects by controlling Variation Type, Variation Item and Destination definitions within Zuken via tool integration to pure::variants. pure::variants can generate the destination for a particular variant and also load the destinations created manually in Zuken CR-8000 into pure::variants. With this, it is possible to analyze the manually configured destinations. The pure::variants integration provides an editor for variability information. It provides visualizations to preview variants and helps finding errors in variability information directly in Zuken CR-8000.

The image shows highlights of pure::variants connector for Zuken in the form of a word cloud which are Destinations, Structural variability, Holistic variant management, Manage complexity, reuse requirements, systematic variant management, system modelling, partial configuration, simple expression language, Parametric variability.
© pure-systems GmbH

Additional benefits

  • Enables creation of new or updated Zuken destinations based on a set of variant models using Zuken transformation.
  • Ensures correctness of restrictions by providing an error check.
  • Allows feature-based tailoring and automated generation of model variants.
  • Expresses interdependencies between variation items in one board design.
  • Enables variant management in multi-board systems and provides consistency.
